Pressure transducers are crucial in modern industry. They convert changes in mechanical pressure into electrical signals, enabling precise measurements. This guide will help you understand how they work and their applications.

Syscom-Prorep, expert in industrial electronic solutions for 30 years, guides you through the world of pressure transducers. This guide will give you the keys to selecting the ideal pressure transducer for your needs.

Pressure sensors measure the force of a fluid on a surface. This measurement is expressed in Pascals (Pa), bars or pounds per square inch (psi). These tools are essential in the automotive, aerospace, medical and food industries.

Key points to remember

  • Pressure transducers convert mechanical pressure into an electrical signal
  • They measure the force exerted by a fluid on a surface.
  • Common units are Pascal, bar and psi.
  • There are different types of sensors for different applications
  • Their applications range from automotive to aerospace.
  • The choice of sensor depends on factors such as accuracy and environmental conditions.

Fundamentals of pressure transducers

Pressure sensors are crucial in many industrial sectors. These devices, like strain gauges or transmitters, measure and control pressure in various systems. Their versatility makes them indispensable for many applications.

Definition and basic operation

A pressure transducer converts the pressure of a fluid or gas into a measurable electrical signal. Common types include piezoelectric, ceramic and diffused silicon sensors. Each type offers specific advantages, depending on its intended use.

Pressure calculation formula

Pressure is defined as the force applied to a given surface. It is expressed by the formula :

P = F / S

P represents pressure in N/m², F the force in Newtons, and S the surface area in m².

Importance in modern industry

Pressure sensors are ubiquitous in modern industry. The automotive sector uses MEMS transmitters for engine management and tire monitoring.

The petrochemical industry uses pressure switches to measure differential and absolute pressures. In medicine, these sensors enable precise measurements during minimally invasive procedures.

Sensor typeApplicationMain benefitPiezoelectricAviation, automotiveCompact and durableCeramicDemanding environmentsPrecision and stabilityDiffused siliconGeneral applicationsHigh sensitivity

Pressure transducer types

Pressure transducers are crucial for measuring pressure in industry. Several types are available, each adapted to specific uses. Their choice depends on the specific needs of the application.

Piezoresistive sensors

These sensors use materials that change electrical resistance under pressure. They are renowned for their sensitivity and robustness. Their measurement capacity reaches 1000 bar, making them suitable for a wide range of applications.

Capacitive sensors

Capacitive sensors measure pressure via variations in electrical capacitance. They excel at measuring low pressures, in the mbar range. Their range is limited to around 40 bar, restricting their industrial use.

Piezoelectric sensors

These sensors convert pressure into an electrical signal using the piezoelectric effect. They measure pressures up to 8000 bar. They are frequently used in extreme conditions, withstanding temperatures of up to 700°C.

Optical sensors

Optical sensors use light to measure pressure. They are effective in environments with electromagnetic interference. Their accuracy makes them popular in specialized fields such as aerospace.

For an industrial electronic pressure gauge, a piezoresistive sensor from 0 to 600 bar with 0.3% accuracy would be appropriate. More detailed measurements would require a capacitive sensor.

Advanced measurement technologies

Sensor technologies are evolving rapidly, offering innovative solutions for pressure measurement. MEMS sensors represent a major advance in this field. These miniature devices measure dimensions in the nanometer range. Their small size and precision make them invaluable tools for a variety of industrial applications.

Modern pressure transducers incorporate advanced features. ATEX SIL 2 and SIL 3 industrial pressure transducers continuously measure liquids, gases and vapors in hazardous environments. These devices offer unrivalled accuracy, stability and reliability, essential for the chemical and petrochemical industries.

Artificial intelligence and the Internet of Things are integrated into sensor technology. This digitization enables instantaneous data collection and analysis. This enables companies to make informed decisions based on accurate, real-time information. This improves their operational efficiency and strengthens their market position.

Innovations in pressure measurement extend to specific applications. Pressure transducers for hydrogen, manufactured in France, meet the industry's specific needs. Qualified sensors for the nuclear industry guarantee high precision in demanding environments.

Units of measurement and conversions

Pressure measurement uses a variety of units, depending on the application and the region. Modern instrumentation must take these different units into account to guarantee optimum accuracy. This diversity is essential in the industrial and scientific fields.

International system (Pascal)

The Pascal (Pa) is the International System's basic unit for measuring pressure. It is equivalent to a force of one newton applied to a surface area of one square meter. Industry often uses multiples such as the kilopascal (kPa) or megapascal (MPa) for higher pressures.

Other common units

The bar and the millimeter of mercury (mmHg) are frequently used. One bar is worth 100,000 Pa, while one mmHg is equivalent to 133.322368 Pa. The psi (pound per square inch) is common in English-speaking countries, with 1 psi ≈ 6894.76 Pa.

Conversion table

UnitEquivalence in Pascal (Pa)1 bar100 0001 atmosphere (atm)101 3251 mmHg133.3223681 psi6894.761 hectopascal (hPa)100

Mastery of these units and their conversions is crucial to the efficient use of pressure instrumentation. Modern transducers can often display multiple units, making it easier to read according to user preferences. This flexibility improves efficiency in a variety of industrial and scientific contexts.

Industrial pressure sensor applications

Pressure sensors are indispensable in many industrial sectors. They optimize processes, guarantee safety and improve operational efficiency. Let's take a look at their use in three key areas.

Automotive sector

The automotive industry relies heavily on pressure sensors. They control tire pressure, ensuring safety and fuel economy. These sensors also regulate engine operation to optimize performance.

A sensor in a tire with a contact area of 0.2 m² and a force of 2500 N would measure a pressure of 12500 Pascals.

Medical industry

Pressure sensors are ubiquitous in the medical industry. They are essential for monitoring blood pressure and accurately tracking patient health. These strain gauges are crucial in artificial respirators, ensuring adequate ventilation in intensive care.

Aerospace

In aerospace, pressure sensors are vital. They measure altitude and atmospheric pressure, crucial data for navigation. These sensors also monitor cabin pressure, ensuring passenger comfort and safety.

Their measurement range varies from 0-20 Bar to 0-400 Bar, adapted to the extreme conditions of aviation.

SectorApplicationMeasurement rangeAutomotiveTire pressure0-5 BarMedicalBlood pressure0-300 mmHgAerospaceCabin pressure0-400 Bar

Pressure sensors, whether simple detectors or sophisticated gauges, are key components in these industries. Their accuracy and reliability are crucial to ensuring the safety and efficiency of modern industrial processes.

Key technical data

The technical characteristics of pressure sensors are crucial to their performance. Accuracy, a key factor, is influenced by ambient temperature and the temperature of the fluid being measured. An error rate of 0.2% per degree Celsius over 10°C can result in a 2% deviation from full scale.

Measurement range is an essential aspect. For a hydraulic system at 137.8 bar, an ideal transducer would have a range between 103.4 and 172.3 bar. Resolution is also important. A transmitter with a full scale of 100 psi and a resolution of 0.1% will detect changes of 0.1 psi.

Long-term stability and environmental resistance maintain measurement reliability. Electronic pressure gauges for the food and pharmaceutical industries can include flush diaphragm versions. Some pressure switches feature self-calibration, reducing maintenance and downtime.

CharacteristicExamplePrecision0.5% of full outputMeasurement range0 to 6.9 barResolution0.1% of full scaleOverpressure protectionUp to 206.8 bar

Response time is vital for real-time applications, such as medical ventilators. Output signals can be analog or digital, offering flexibility of integration into a variety of industrial control systems.

Pressure transducer selection criteria

Choosing the right pressure transducer is essential for accurate measurements. Several key factors influence its performance in your specific application. Selection depends on these important criteria.

Accuracy required

Sensor accuracy varies according to the application. HVAC systems tolerate a non-linearity of ±0.6%. Calibration requires higher accuracy, with a non-linearity of ±0.04% or less.

WIKA sensors offer a range from -1 to 1300 bar. The HP-2 model can measure up to 15,000 bar.

Environmental conditions

The operating environment has a major influence on the choice of sensor. Outdoor use requires an IP67 rating. Submersible applications require IP68.

Environments exposed to high-pressure steam require IP6K9K. In potentially explosive areas, intrinsically safe sensors are essential.

Interface compatibility

Transducer technology needs to integrate easily into your existing systems. Modern transducers offer 4-20 mA analog signals and digital interfaces such as IO-Link.

Consider the complexity of the sensor. Additional features may affect size, power consumption and temperature range.

These criteria will help you choose the optimum pressure transducer. This will ensure reliable and accurate measurements in your industrial application.

Installation and maintenance

Installation and maintenance of pressure sensors are essential for optimum performance. Precise installation guarantees accurate measurements. Regular maintenance extends the life of the instrumentation.

For installation, please note the following key points:

  • Check the sensor's compatibility with your environment
  • Make sure the measurement range matches your needs
  • Follow the manufacturer's installation instructions
  • Use the appropriate tools and observe the tightening torque.

Preventive maintenance of strain gages includes :

  • Regular calibration to maintain accuracy
  • Cleaning adapted to the environment
  • Visual inspection for signs of wear
  • Checking electrical connections

Modern pressure transducers offer impressive technical features:

CharacteristicValueAccuracy±0.5% of spanTemperature range-10 to 60 °CIP 65 protectionAnalog output1 to 5 V or 4 to 20 mA

Specialized technical support is crucial to successful installation and maintenance. Experts can guide you in your choice of pressure instrumentation. Their expertise ensures optimum performance over the long term.

Modern connectivity solutions

Information technology is rapidly transforming pressure sensors. Electronic transmitters, pressure switches and pressure gauges are adapting to the digital age. They offer advanced connectivity solutions to meet today's needs.

IoT integration

The Internet of Things (IoT) is revolutionizing pressure data management. The industrial IoT market is expected to grow by 23.2% per year between 2023 and 2030. Connected pressure sensors are becoming essential for real-time monitoring.

This integration improves productivity and reduces downtime. It enables more efficient management of industrial processes.

Digital interfaces

Modern digital interfaces facilitate communication between sensors and control systems. Transmitters with digital outputs offer enhanced accuracy. They are more resistant to interference, guaranteeing reliable measurements.

Intelligent pressure switches enable thresholds to be adjusted remotely. This feature optimizes industrial processes, increasing operational efficiency.

Communication protocols

LoRa, GNSS, Wi-Fi and Bluetooth are now commonplace in the pressure sensor industry. These technologies enable long-range, low-power wireless connectivity. They are ideal for complex industrial environments.

IO-Link, supported by over 120 companies, offers bi-directional communication. It efficiently links sensors to controllers, improving data management.

ProtocolAdvantagesTypical applicationsLoRaLong range, low power consumptionRemote monitoring of pipelinesGNSSaccurate geolocationTracking of mobile equipmentWi-FiHigh speed, wide compatibilityFactory control systemsBluetoothLow power, short rangeOn-site diagnostics

These advances in connectivity optimize industrial operations. They increase asset availability by 1-2% thanks to predictive alerts. These improvements generate significant savings by reducing breakdowns and downtime.

Standards and certifications

Standards and certifications are essential for pressure instrumentation. They guarantee the reliability and accuracy of sensors. Fuji Electric's FCX-AIV series has SIL 3 certification, in compliance with IEC 61508:2010.

ISO 376:2011 revolutionized force transducer calibration in 2012. It introduced new classification criteria, replacing hysteresis with creep. This evolution improves the precision of instruments in various industrial sectors.

Pressure transducer manufacturers are constantly adapting to new requirements. HBM, accredited since 1977, offers a wide range of force transducers. Their products range from 2.5 N to 5 MN in tension and compression.

HBM's calibration certificates provide detailed information in accordance with ISO 17025. This ensures the quality and reliability of their pressure measurement instruments.

FAQ

What is a pressure sensor and how does it work?

A pressure sensor measures the force exerted by a fluid or gas on a surface. It converts this physical force into a measurable electrical signal. The main types are piezoresistive, capacitive, piezoelectric and optical. Each uses a different principle to perform this conversion.

What are the common units of measurement for pressure?

Common units include Pascal (Pa), bar and millimeter of mercury (mmHg). The choice depends on the application and industry. Bar is common in industry, mmHg in medicine for blood pressure.

What are typical industrial applications for pressure sensors?

In the automotive industry, they monitor tire pressure and manage the engine. In medicine, they are essential for blood pressure monitors and breathing apparatus. In aerospace, they measure altitude and monitor cabin pressure.

How do I choose the right pressure sensor for my application?

The choice depends on the accuracy required, environmental conditions and interface compatibility. Consider the type of sensor (piezoresistive, capacitive) best suited to your specific application.

How important is pressure sensor maintenance?

Regular maintenance ensures precision and longevity. It includes calibration, cleaning and inspection for wear. Proper maintenance ensures reliable measurements and extends sensor life.

How are IoT technologies integrated into pressure sensors?

IoT integration enables real-time data collection and analysis. It uses specific digital interfaces and communication protocols. LoRa, GNSS, Wi-Fi and Bluetooth connect sensors to networks, facilitating remote monitoring and advanced analysis.

What are the latest innovations in pressure sensor technology?

Innovations include MEMS sensors offering advanced miniaturization. Fiber optic sensors enable precise measurements in harsh environments. These technologies improve precision, reliability and miniaturization, opening up new possibilities for industrial applications.

How important are standards and certifications for pressure sensors?

Standards guarantee sensor quality, safety and reliability. They ensure compliance with performance and safety requirements. Certain certifications are mandatory for medical applications or hazardous environments. Compliance with these standards is crucial to regulatory compliance and user safety.

‍
